项目Items

技术指标

Value

检测仪器

Test Instrument

检测标准

Test Method

颜色 Color

粉红色 pink

目视Visual

--

厚度(mm)

Thickness

0.3~18

PEACOCK厚度规

PEACOCK THICKNESS METER

ASTM D 374

规格

Specification

根据客户要求

Can be Custom-made

数显卡尺

DIGITAL CALIPER

ASTM D 5947

密度(g/cc)

Density

2.62(±0.5)

ZMD-2电子密度仪

ZMD-2 ELECTRONIC DENSIMETER

ASTM D 792

硬度(Shore A)

Hardness

10~55(±5)

LX-C型微孔材料硬度计

LX-C CELLULAR MATERIAL DUROMETER

ASTM D 2240

导热系数(W/m·K)

Thermal Conductivity

1.5(±0.2)

LW-9389导热系数测试仪

LW-9389THERMAL CONDUCTIVITY TESTER

ASTM D 5470

热阻(℃in2/W)(@20psi&1mm)

Thermal Resistance

≤1.5

LW-9389导热系数测试仪

LW-9389THERMAL CONDUCTIVITY TESTER

ASTM D 5470

击穿电压(kV)(@1mm)

Breakdown Voltage

≥8

MS2676A耐压测试仪

MS2676A WITHSTAND VOLTAGE TESTER

ASTM D 149

体积电阻率(Ω.cm)

Volume Resistivity

≥10⁸

ZC-36高绝缘电阻测量仪

ZC-36 HIGH DIELECTRIC RESISTANCE TESTER

ASTM D 257

压缩比(%)(@50psi)

Compression Ratio

≥25

HY939CS压缩力测试仪

HY939CS COMPRESSINVE FORCE TESTER

ASTM D 575

拉伸强度 (MPa)

Tensile Strength

≥0.25

HY939CS拉力试验机

HY939CS TENSION TESTER

ASTM D 412

延伸率(%) Elongation

≥80

介电常数(@1MHz)

Dielectric Constant

≥2

WY2851D数显Q表

WY2851D DIGITAL Q METER

ASTM D 150

介质损耗(@1MHz)Dielectric Loss

≤0.1

防火性能 UL Certify

UL94-V0.5V

阻燃测试仪 FLAME RATING TESTER

UL 94

使用温度 (℃)

Operating Temperature

-50~200

XB-OTS-150D-C可程式冷热冲击箱

PROGRAMMABLE THERMAL SHOCK TESTER

IEC 60068-2-14
